HD CVBS SDI VGA HEVC HTTP IPTV Streaming H.264 Encoder Manufacturer
Short Description:
| Shineco(full-interface) /VGA/CVBS/YPBPR/SDI HD encoder | |
| Input | 1-channel /VGA/CVBS/YPBPR/SDI input |
| Output | 2-channel IP signal output, 1-channel SDI loop out |
| Video | |
| Input resolution | 1920x1080/1680x1050/1280x720/1600x1200/960x540/720*576/704*576 etc. |
| Coding standard | H.264 |
| Coding level | H.264 BASELINE PROFILE H.264 MAIN PROFILE H.264 HIGH PROFILE |
| Encoded size | 640*360~1920*1080(Can customize) |
| Video bit rate | Rate control: CBR/VBR 16KBIT/S~12MBIT/S |
| Video frame rate | 30/60 |
| OSD | Character |
| Audio | |
| Input selection | 1-channel embedded audio , 1-channel embedded audio SDI,2-channel 3.5MM independent audio Support audio gain |
| Audio coding | AAC/MP3/G711 |
| Audio bit rate | 64Kb/s~384Kb/s |
| Sampling rate | 32000,44100 ,48000etc |
| IP output | 2pcs RJ 100M / 1000M adaptive Ethernet port, TS stream standard, dual-stream, ONVIF protocol |
| System | |
| Network protocol | HTTP, RTSP, RTMP, UDP, HLS multicast, unicast |
| Configuration management | Support IE configuration, remote upgrade |
| power consumption | |
| 5w | |
| Operating temperature | -20℃+ 60℃ |
| Working humidity | <90%,Non-condensing |
| Weight | 0.5KG |
