Optic Cable Assembly Fast Connector Fiber Mechanical splice for emergency repair fiber cercuit
Short Description:
| Feature | |
| Requirement | |
| General | |
| Cable type | |
| 2.0 x 3.1 mm drop cable | |
| Applicable mode | |
| single | |
| Product dimension | |
| 90*8*7mm | |
| Color | |
| Black | |
| Availability of sufficient gel | |
| Yes | |
| Characteristics | |
| Insertion loss | |
| ≤ 0.30dB | |
| Return loss | |
| ≤ -50dB | |
| Success rate | |
| >98% | |
| Reusability times | |
| ≥10times | |
| Fastening strength of naked fiber | |
| >5 N ΔIL≤ 0.1dB | |
| Clamping force of fiber with tight buffer | |
| >8 N ΔIL≤ 0.1dB | |
| Tensile strength | |
| >50 N IL ≤ 0.2dB | |
| Drop off test (4 meters high, cement floor, three directions | |
| IL ≤ 0.3dB | |
| OtherRequirements | |
| Optical fiber cladding diameter | |
| 125μm (G.657 A2) | |
| Work temperature | |
| -40 ~+75C | |
| Material Durability | |
| Must withstand solar U V radiation |
