| Specifications |
|
AR1220
|
|
AR1220-D
|
AR1220C
|
|
WAN Speed with Services***
|
|
200 Mbit/s
|
|
200 Mbit/s
|
200 Mbit/s
|
|
Fixed WAN Ports
|
|
2 x GE
|
|
2 x GE
|
4 x GE+ 1 x GE SFP
|
|
Fixed LAN Ports
|
|
8 x FE (can be configured as WAN interfaces)
|
|
8 x FE (can be configured as WAN interfaces)
|
8 x GE (can be configured as WAN interfaces)
|
|
Slots
|
SIC slots: 2
WSIC slots (default/max): 0/1
|
|
3G/LTE
|
FDD LTE: Uplink: 50 Mbit/s; Downlink: 100 Mbit/s
WCDMA
|
|
Wireless Controller
|
Wireless Controller is integrated in software
|
|
Wi-Fi
|
|
-
|
|
-
|
-
|
|
Memory
|
|
512 MB
|
|
512 MB
|
512 MB
|
|
Maintenance
|
All interface cards support hot swapping U-disk deployment supported
|
|
Power Supply
|
|
AC: 100V to 240V, 50 Hz/60 Hz
|
|
AC: 100V to 240V, 50 Hz/60 Hz DC: –42V to –53V
|
|
AC: 100V to 240V, 50 Hz/60 Hz
|
|
Dimensions (H x W x D)
|
44.5 mm x 390 mm x 220 mm
|
