Huawei CloudEngine S5736-S Series All-Optical 24 Ports Switch S5736-S24S4XC
Short Description:
| Parameters | |
| CloudEngine S5736-S24S4XC | |
| CloudEngine S5736-S48S4XC | CloudEngine S5736-S48S4X-A |
| Forwarding Performance | |
| 240 mpps | |
| 240 mpps | 480 mpps |
| Switching Capacity2 | |
| 448 Gbit/s / 1.36 Tbit/s | |
| 496 Gbit/s / 1.36 Tbit/s | 1.04/2.72 Tbit/s |
| Fixed Ports | |
| 24 x GE SFP ports, 4 x 10 GE SFP+ ports | |
| 48 x GE SFP ports, 4 x 10 GE SFP+ ports | |
| 48 x GE SFP ports, 4 x 10 GE SFP+ ports | |
| Flexible Upgrade | |
| Not supported | |
| Not supported | Smooth upgrade of downlink ports from GE to 10 GE based on RTU licenses |
| MAC Features | IEEE 802.1d complianceAutomatic MAC address learning and agingStatic, dynamic, and blackhole MAC address entriesPacket filtering based on source MAC addresses |
| VLAN Features | 4094 VLANsGuest VLAN and voice VLANGVRPMUX VLANVLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports1:1 and N:1 VLAN mapping |
| IP Routing | Static route, RIPv1/v2, RIPng, OSPF, OSPFv3, ECMP, IS-IS, IS-ISv6, BGP, BGP4+ |
| Super Virtual Fabric (SVF) | Plug-and-play of SVF clientsAutomatic software package and patch loading to SVF clientsOne-click and automatic delivery of service configurationsIndependent SVF client running |
