Processor
|
Dual-core, 700 MHz
|
|
Memory
|
256 MB
|
|
Flash
|
512 MB
|
|
Dimensions (W x D x H)
|
150 mm x 133 mm x 44 mm (5.91 in. x 5.24 in. x 1.73 in.), 1 U height
|
|
Weight
|
1.1 kg (2.43 lb)
|
|
Maximum power consumption
|
17 W
|
|
DC power input
|
Rated voltage: 54 V DC
Maximum voltage range: 44 V DC to 57 V DC
|
|
DO attributes
|
Input withstand voltage: 60 V DC
Current rating: 1.0 A
|
|
DI attributes
|
Rated voltage: 9.6 V DC to 60 V DC
|
|
Console interfaces
|
1
|
|
USB interfaces
|
1
|
|
RS485 interfaces
|
1
|
|
DO interfaces
|
1
|
|
DI interfaces
|
1
|
|
Service interfaces
|
Six GE electrical interfaces
Two GE combo interfaces and two 2.5GE optical interfaces
|
