Huawei S5720I-SI Series S5720I-10X-PWH-SI-AC Video Backhaul Switch
Short Description:
| Parameters | |
| S5720I-6X-PWH-SI-AC | S5720I-10X-PWH-SI-AC |
| Switching Capacity | |
| 168 Gbit/s | 168 Gbit/s |
| Forwarding Performance | |
| 35.7 Mpps | 42 Mpps |
| Fixed Ports | |
| 4 x Ethernet 10/100/1,000 ports, 2 x 10 Gig SFP+ | 8 x Ethernet 10/100/1,000 ports, 2 x 10 Gig SFP+ |
| PoE | |
| 4 PoE++ ports | 8 PoE++ ports |
| Operating Voltage | |
| Rated AC voltage: 220V to 240V, 50/60 HzMaximum AC voltage: 176V to 264V, 45 Hz to 66 Hz | Rated AC voltage: 100V to 240V; 50/60 HzMax AC voltage: 90V to 264V; 47 Hz to 63 Hz |
| Operating Temperature | 0m to 1,800m altitude: -40°C to +55°C1,800m to 5,000m altitude: The operating temperature reduces by 1°C fro each 220m increase in altitude.Supports startup in -40°C. |
| Surge Protection | Built-in surge protection to best suit harsh outdoor environments |
| IP Code | IP66 |
| Relative Humidity | 5% to 95% (non-condensing) |
| Heat dissipation | Natural heat dissipation without fans |
