Specifications
|
F01C50
|
F01E50
|
F01S100
|
F01S200
|
F01S300
|
F01D500
|
Dimensions (H x W x D)
|
600 mm x 550 mm x 160 mm
|
860 mm x 600 mm x 180 mm
|
830 mm x 670 mm x 250 mm
|
850 mm x 750 mm x 350 mm
|
1,350 mm x 850 mm x 450 mm
|
1,650 mm x 1,550 mm x 550 mm
|
Devices
|
1 x MA5620
1 x MA5626
1 x MA5623
1 x MA5612
|
1 x MA5616
|
1 x MA5616
|
1 x MA5616
|
3 x MA5616/1 x MA5603T
|
1 x MA5600T
|
Service Capacity
|
< 48 lines
|
< 128 lines
|
< 128 lines
|
< 192 lines
|
< 384 lines
|
< 1,024 lines
|
Installation Scenarios
|
Corridor and indoor
|
Corridor, basement, and indoor
|
Outdoor
|
Outdoor
|
Outdoor
|
Outdoor
|
Installation Modes
|
Pole-mounted or wall-mounted
|
Pole-mounted, wall-mounted, and base-installed
|
Pole-mounted, wall-mounted, and base-installed
|
Pole-mounted, wall-mounted, and base-installed
|
Base-installed
|
Base-installed
|
Operating Environment
|
–25°C to +45°C
|
–25°C to +45°C
|
–33°C to +45°C
(1,120W/m² solar radiation)
|
–33°C to +45°C (1,120W/m² solar radiation)
|
–33°C to +45°C (1,120W/m² solar radiation)
|
–40°C to +45°C
(1,120W/m² solar radiation)
|
Water-proof and Dust-proof Rating
|
IP31
|
IP31
|
IP55
|
IP55
|
IP55
|
IP55
|
Noise Rating
|
Class4.1 protected-area level
|
Class4.1E protected-area level
|
Class4.1 protected-area level
|
Class4.1E protected-area level
|
Class4.1E protected-area level
|
Class 4.1E city level
|
Weight
|
15.7 kg
|
49 kg
|
58 kg
|
85 kg
|
270 kg
|
417 kg
|
