| Product Name |
HA7004S EPON OLT |
| Wavelength |
1310（RX）/1490（TX） |
| Optical power |
+2.5~ +7dBm |
| Receiving Sensitivity |
-27dBm |
| Maximum distance |
20km |
| Maximum optic ratio |
1:64 |
| Capacity |
4PON System, 256 ONUs |
| MAC |
16K |
| Port |
4 Gigabit SFP PON ports |
|
4 GE Uplink ports |
|
1 FE management port |
|
1 RS232 DB9 serial port |
| MTBF |
100000 hours |
| Feature |
Support IEEE802.3ah |
|
Support DBA with minimum1Kbps granularity adjustable |
|
Support 1Gbps up link and down link symmetrical bandwidth |
|
Support AES-128 encryption to each Logical Link Identifier |
|
Support powerful OAM function, implement telnet management, maintenance and upgrade |
|
Support auto discovery and auto register of ONU (real-time operation) |
| Standard |
Support IEEE802.3, IEEE802.3u, IEEE802.3ab |
|
Support IEEE802.1Q VLAN |
|
Support IEEE 802.1P QoS |
| Network management |
Support GUI management based on SNMP (work with rack) |
|
Support WEB / CLI |
