Huawei CWDM DWDM fiber optical multiplexer OSN1800
Short Description:
| Item | |
| N63E/N63B Cabinet | |
| 19-Inch Cabinet | 19-Inch Open Rack |
| Appearance | |
| NOTE: N63E cabinets use front columns while N63B cabinets use middle columns. | |
| Weight | |
| N63E cabinet: 45 kg (99.2 lb.) N63B cabinet: 60 kg (132.3 lb.) | |
| 76 kg (167.6 lb.) | 2200 mm-high cabinet: 25 kg (55.1 lb.) 2000 mm-high cabinet: 22 kg (48.5 lb.) |
| Dimensions (H x W x D) | |
| 2200 mm x 600 mm x 300 mm (86.6 in. x 23.6 in. x 11.8 in.) | |
| 2200 mm x 600 mm x 600 mm (86.6 in. x 23.6 in. x 23.6 in.) | 2200 mm x 600 mm x 600 mm (86.6 in. x 23.6 in. x 23.6 in.) 2000 mm x 600 mm x 600 mm (78.7 in. x 23.6 in. x 23.6 in.) |
| Available space | |
| 45 U | |
| 45 U | 2200 mm (height): 45 U 2000 mm (height): 40 U |
| Space required by the hardware | Ordinary OptiX OSN 1800 I chassis: 1 U OptiX OSN 1800 I chassis integrated with an FMT: 2 U Ordinary OptiX OSN 1800 II chassis: 2 U OptiX OSN 1800 II chassis integrated with an FMT: 3 U DC power distribution unit (PDU): 3 U FMT: 1 U Dispersion compensation module (DCM) frame: 1 U |
