| Parameter |
Specifications |
| Operating wavelength |
1310(RX)/1490(TX) |
| Optical power |
+0 ~ +7dBm |
| Receiving sensitivity |
-27dBm |
| Max distance |
20km |
| Max splitter ratio |
1:64 |
| Capacity |
2 PON, standard: 64 ONUs maximum:128 ONUs |
| MAC |
8K |
| Uplink port |
2 1000M Ethernet RJ45 ports |
| PON port |
2 SFP fiber ports |
| Control port |
RJ45 console port, to debug the device |
| MTBF |
100,000 hours |
| EPON traits |
Support IEEE802.3ah |
|
Support DBA with minimum1Kbps granularity adjustable |
|
Support 1Gbps up link and down link symmetrical bandwidth |
|
Support AES-128 encryption to each Logical Link Identifier |
|
Support powerful OAM function, implement telnet management, maintenance and upgrade |
|
Support auto discovery and auto register of ONU (real-time operation) |
| Protocols supported |
Support IEEE802.3, IEEE802.3u, IEEE802.3ab |
|
Support IEEE802.1Q VLAN |
|
Support IEEE 802.1P QoS |
| Management |
CLI and GUI, SNMP, WEB |
|
Support DHCP Snooping |
|
Support Ipv4 address learning based at DHCP Snooping |
|
Support ARP Snooping, QoS etc |
