Huawei CloudEngine S5735-S-IA Series Video Backhaul Switch S5735-S8P2X-IA200H1
Short Description:
| Product Model | |
| CloudEngine S5735-S8P2X-IA200G1 | CloudEngine S5735-S8P2X-IA200H1 |
| Forwarding Performance | |
| 41.7 mpps | 41.7 mpps |
| Switching Capacity | |
| 168 Gbit/s | 168 Gbit/s |
| Ports | |
| 8 x 10/100/1000Base-T Ethernet ports and 2 x 10 GE SFP+ ports | 8 x 10/100/1000Base-T PoE+ ports and 2 x 10 GE SFP+ ports |
| Power Supply Type | |
| Mains | Mains, solar, and lithium battery |
| PoE | |
| 8 PoE+ ports | 8 PoE+ ports |
| Operating Temperature | |
| –40°C to +75°C | –40°C to +55°C (using battery as backup power) |
| Surge Protection | |
| Built-in surge protection to handle harsh outdoor environments | Built-in surge protection to handle harsh outdoor environments |
| IP Rating | |
| IP55 | IP55 |
| Heat Dissipation | |
| Natural heat dissipation without fans | Natural heat dissipation without fans |
